206KRRB Agricultural Bearing

1-Inch Hex Bore Agricultural Bearing for Planters, Seeders and Farm Machinery

The 206KRRB Agricultural Bearing is a sealed insert bearing designed for agricultural machinery using a compatible 1-inch hex shaft. Its hexagonal bore provides positive shaft engagement for applications requiring reliable torque transmission, while the double-sided sealing helps protect the bearing against dust, soil, moisture, and other common agricultural contaminants.

With a 62 mm outside diameter and 24 mm overall width, the 206KRRB is suitable for compatible agricultural equipment and aftermarket replacement applications.

1-Inch Hex Bore | Double Sealed | Spherical Outer Ring | GCr15 Steel | Factory-Filled Grease

206KRRB Quick Specifications

Need to replace an existing bearing? Send us the bearing number, dimensions, shaft size, or product photo for compatibility verification.

206KRRB Technical Specifications

*Load ratings and weight are configuration-dependent. Confirm the final SKET technical drawing or datasheet before using these values for engineering calculations or OEM replacement.

Key Features of the 206KRRB

1-Inch Hex Bore

The 1-inch hex bore is the defining feature of the 206KRRB.

Designed for a compatible hex shaft, it provides positive mechanical engagement and supports torque transmission in agricultural equipment.

Key benefits include:

• Positive shaft engagement

• Reliable torque transmission

• Compatibility with 1-inch hex shafts

• Suitable for agricultural equipment designed around hex-shaft assemblies

Double-Sided Sealing

Agricultural machinery operates in environments where dust, soil, moisture, and plant residue can affect bearing performance.

The double-sided seal helps reduce contaminant entry and retain internal grease, supporting reliable operation in outdoor agricultural applications.

Actual sealing performance depends on operating conditions, shaft condition, installation, and contamination exposure.

Spherical Outer Ring

The spherical outer ring is designed for use with compatible agricultural bearing housings.

Its spherical surface allows a certain degree of housing alignment variation and is suitable for agricultural assemblies exposed to vibration and structural movement.

Housing dimensions and fit should be verified before replacement.

206KRRB Replacement & Compatibility

The 206KRRB agricultural bearing can be used as an OEM or aftermarket replacement when its bore configuration, dimensions, housing fit, sealing arrangement, and application requirements match the original bearing.

For agricultural equipment using a 1-inch hex shaft, verify the bearing-to-shaft interface and key mounting dimensions before ordering.

Key Compatibility Specifications

What to Check Before Replacement

Before replacing an existing agricultural bearing, confirm:

• Bearing number or OEM reference

• Hex shaft size and geometry

• Outside diameter

• Overall width

• Inner-ring width

• Housing dimensions

• Seal configuration

• Load and operating conditions

Matching the nominal bearing number alone does not guarantee interchangeability. The shaft, housing, dimensions, sealing arrangement, and operating conditions should also be compatible.

OEM Replacement Verification

For OEM and aftermarket replacement projects, provide any available information, such as:

• Existing bearing number

• Original manufacturer

• Equipment model

• Shaft size

• Bearing dimensions

• Product drawing

• Product photo

• Required quantity

Our technical team can review the available information and help evaluate whether the 206KRRB is a suitable replacement.

Need to verify a replacement? Send us the existing bearing number, dimensions, shaft size, or product photo.

Agricultural Applications

The 206KRRB is designed for compatible agricultural machinery using a 1-inch hex shaft.

Actual bearing selection should be based on the equipment design, load, speed, and operating environment.

206KRRB Procurement Information

The 206KRRB is available for compatible OEM replacement, aftermarket applications, distributor supply, and bulk purchasing.

*Lead time depends on stock status, order quantity, production schedule, and product configuration.

Quality and Technical Support

Each production batch can be subject to inspection covering key product characteristics such as:

• Dimensional accuracy

• Hex bore geometry

• Raceway condition

• Rotation performance

• Seal condition

• Grease filling

• Final appearance and marking

• Batch traceability

Technical support may include:

• Product technical drawing

• Dimensional datasheet

• Inspection documentation

• OEM replacement evaluation

• Sample testing support

Technical documents and inspection requirements can be discussed according to the customer's application and procurement requirements.

Installation Reference

For reliable installation:

1. Check the hex shaft for correct size, wear, corrosion, or deformation.

2. Verify the housing dimensions and mounting condition.

3. Align the hex bore with the shaft before installation.

4. Avoid direct impact on the rolling elements, raceways, or seals.

5. Check rotation after installation for abnormal resistance or noise.

Do not force an incorrectly sized hex bore onto the shaft.

Frequently Asked Questions

What is a 206KRRB agricultural bearing?

The 206KRRB is a sealed agricultural insert bearing featuring a 1-inch hex bore, double-sided sealing, and a spherical outer ring for compatible farm machinery applications.

What size shaft does a 206KRRB fit?

The bearing is designed for a compatible 1-inch hexagonal shaft. Shaft geometry and dimensions should be verified before installation.

What are the dimensions of a 206KRRB?

A common configuration uses a 1-inch hex bore, 62 mm outside diameter, and 24 mm overall width. Confirm the final technical drawing before ordering.

What is the advantage of a hex bore bearing?

A hex bore provides positive mechanical engagement with a compatible hex shaft and supports torque transmission in agricultural machinery designed for this shaft configuration.

Can 206KRRB replace an OEM agricultural bearing?

It can be used as an OEM or aftermarket replacement when the shaft, bore, outside diameter, width, housing, sealing arrangement, and application requirements are compatible.

How can I verify 206KRRB replacement compatibility?

Send us the existing bearing number, dimensions, shaft size, equipment model, or product photo. Our technical team can review the information and help evaluate compatibility.

Request 206KRRB Replacement Verification

Looking for a reliable 206KRRB agricultural bearing supplier for OEM replacement, distributor supply, or bulk purchasing?

We can support:

• 206KRRB specification verification

• 1-inch hex bore compatibility checks

• OEM replacement evaluation

• Technical drawing review

• Sample orders

• Bulk purchasing

• Export packaging

• Batch inspection

Have an Existing Bearing to Replace?

Send us:

Bearing Number + Shaft Size + Bearing Dimensions + Equipment Model + Product Photo

Our technical team can help evaluate the 206KRRB replacement compatibility and provide a suitable quotation.
