The SKET 5203KYY2 agricultural bearing is a sealed double-row bearing designed for planter and agricultural machinery applications. It features a 16.256 mm bore, 40.000 mm outside diameter and 44.120 mm overall width, with a basic dynamic load rating of 14.02 kN and a basic static load rating of 7.88 kN.
SKET supplies 5203KYY2 bearings for replacement requirements, distributor orders, bulk purchasing and OEM applications. If you are replacing an existing bearing, send us the original bearing number, dimensions or a product photo so we can verify compatibility before quotation.
5203KYY2 Bearing Specifications
| Specification | 5203KYY2 |
|---|---|
| Bearing Type | Agricultural Bearing |
| Bearing Configuration | Double Row |
| Sealing | Sealed |
| Bore Diameter (d) | 16.256 mm / 0.6400 in |
| Outside Diameter (D) | 40.000 mm / 1.5748 in |
| Overall Width (B) | 44.120 mm / 1.7370 in |
| Inner-Ring Width (C) | 39.120 mm / 1.5402 in |
| Basic Dynamic Load Rating (Cr) | 14.02 kN |
| Basic Static Load Rating (Cor) | 7.88 kN |
| Mass | 0.233 kg |
Note: Dimensions and load ratings above are based on the SKET 5203KYY2 product specification. Confirm the required configuration and application conditions before ordering.
Why Choose the SKET 5203KYY2?
The value of the 5203KYY2 is not simply its bearing number. For replacement and procurement projects, the key consideration is whether the bearing provides the required fit, configuration and load capability for the existing equipment.
Double-Row Design for Agricultural Equipment
The double-row configuration provides a bearing arrangement suitable for applications where the equipment design requires a compact bearing with two rows of rolling elements.
For replacement projects, the bearing configuration should be checked together with the original bearing arrangement rather than relying on the part number alone.
Defined Fit for Replacement Applications
The standardized dimensional configuration makes the 5203KYY2 suitable for replacement evaluation when the original bearing has the same required mounting dimensions.
Before ordering, verify the shaft fit, housing fit, available axial space and bearing configuration against the existing assembly.
14.02 kN Dynamic Load Rating
The 14.02 kN basic dynamic load rating provides a defined reference value for bearing selection and life calculations.
Actual bearing life depends on the applied load, rotational speed, lubrication, contamination, alignment, operating temperature and other application conditions. The basic load rating should therefore not be interpreted as the maximum permissible operating load.
Sealed Construction
The sealed configuration is suited to agricultural machinery where protection against contamination and retention of lubricant are important considerations.
Actual sealing performance depends on the seal design, operating environment, temperature, speed and contamination level.
5203KYY2 Bearing Dimensions
For replacement work, dimensional verification is more important than relying on the bearing designation alone.
Use the following dimensions when checking an existing bearing or housing:
- Bore: 16.256 mm
- Outside diameter: 40.000 mm
- Overall width: 44.120 mm
- Inner-ring width: 39.120 mm
When possible, compare the original bearing drawing or physical bearing with the SKET specification before placing a replacement order.
5203KYY2 Replacement Compatibility
A correct replacement requires more than matching the bearing number.
| Replacement Check | What to Verify |
|---|---|
| Bore fit | Shaft diameter and required fit |
| Outside diameter | Housing or mounting location |
| Overall width | Available axial installation space |
| Inner-ring width | Shaft shoulder and mounting arrangement |
| Bearing configuration | Double-row arrangement |
| Sealing | Existing sealing and contamination requirements |
| Load requirement | Applied radial/axial loads and duty conditions |
| Installation | Shaft, housing and mounting method |
Need to Verify a 5203KYY2 Replacement?
Send SKET any of the following:
Original bearing number → Bearing dimensions → Equipment/application → Product photo or drawing
We can use the available information to check the required configuration before quotation.
Request a Replacement Check → Confirm Dimensions → Get a Quote
5203KYY2 Equivalent & Cross Reference
Bearing numbers should not be treated as interchangeable solely because they appear similar in catalogs.
For a replacement project, SKET recommends checking:
- Bearing dimensions
- Bearing configuration
- Sealing arrangement
- Shaft and housing fit
- Load requirements
- Application conditions
If you have a competitor or original-equipment bearing number, send it to SKET for a compatibility review rather than assuming direct interchangeability.
5203KYY2 Agricultural Bearing Applications
The 5203KYY2 can be considered for agricultural machinery applications where its dimensional and bearing configuration requirements match the equipment.
Planter Equipment
Suitable for replacement evaluation in planter assemblies where the existing bearing arrangement corresponds to the 5203KYY2 configuration.
Planting Machinery
For planting machinery, selection should consider shaft dimensions, housing arrangement, operating speed, applied loads and contamination conditions.
Agricultural Bearing Replacement
The 5203KYY2 is also available for replacement and maintenance purchasing. For an existing bearing, providing the original part number and dimensions can speed up compatibility verification.
Quality & Inspection for 5203KYY2 Orders
For B2B replacement and bulk orders, SKET can coordinate inspection and order documentation according to project requirements.
Available options may include:
- Product specification confirmation
- Critical dimensional inspection
- Sample verification
- Pre-shipment inspection
- Inspection documentation
- Certificate of Conformance (where applicable)
- Batch or order identification
- Export packaging
For OEM or distributor projects, inspection requirements can be confirmed before production.
5203KYY2 Agricultural Bearing Supply
SKET supports different purchasing requirements for the 5203KYY2 bearing.
Sample Orders
Samples can be arranged for dimensional, installation or application verification before larger purchases.
Bulk & Distributor Supply
For distributors and agricultural machinery parts suppliers, SKET can discuss quantity, packaging and shipment requirements based on the order.
OEM & Private Label
OEM and private-label requirements can be reviewed according to product specifications, packaging and order quantities.
Export Packaging
Bearings can be prepared for export shipment according to the agreed packaging requirements.
For current availability, MOQ and lead time, contact SKET with your required quantity and destination.
FAQ
Is the 5203KYY2 suitable for planter equipment?
It can be suitable when the planter assembly requires the same bearing configuration and mounting dimensions. The existing bearing and installation arrangement should be checked before replacement.
How do I verify a 5203KYY2 replacement?
Start with the original bearing number, then verify the bore, outside diameter, width, inner-ring configuration, sealing arrangement and application requirements. A bearing photo or drawing can also help with identification.
Can I order 5203KYY2 bearings in bulk?
Yes. SKET can discuss bulk and distributor supply based on required quantity, packaging, destination and other purchasing requirements.
Can SKET provide samples?
Yes. Sample orders can be discussed for dimensional or application verification before a larger order.
Can SKET supply OEM or private-label orders?
OEM and private-label requirements can be evaluated based on the required product specification, packaging, quantity and project requirements.
Request a Quote for 5203KYY2 Agricultural Bearings
For a faster quotation and replacement check, please provide:
- Required quantity
- Original bearing number
- Bearing dimensions
- Equipment or application
- Product photo or drawing
- Required delivery destination
- OEM or private-label requirements, if applicable
